3.5 meter Manual Stacker 1500kg Capacity ARL-CTY-E15-35

Max. load capacity: 1500 kg
Max. lifting height: 3500 mm
Min. height of fork: 90 mm
Overall Length: 1670 mm
Overall Width: 804 mm
Overall Height, mast lowered: 2300 mm
Forks Type: Adjustable
Fork Dimensions (L*W*H): 1150 x 150 x 60 mm

3 People watching this product now!

Original price was: 7,500.00.Current price is: 7,200.00. + VAT

Available on backorder

SKU: ARL-CTY-E15-35 Categories: Lifting & Equipments, Manual Stackers

Brand:

🥳 Get 5% Off on Manual Stackers

Use the coupon code ARL5 at checkout to get 5%* off the Robust Manual Pallet Stacker.

All products

3.5 Meter Manual Stacker (1500kg Capacity) | Model: ARL-CTY-E15-35

The 3.5 meter Manual Stacker 1500kg Capacity ARL-CTY-E15-35 is a heavy-duty, reliable solution for manual transport and high-reach lifting. Engineered for precision and safety, this stacker features reinforced high-quality steel forks and a specialized foot brake system to ensure maximum stability during operation. Whether you are managing a warehouse or a workshop, this 1500kg capacity lifter is built for professional durability.

At a Glance 3.5 meter Manual Stacker 1500kg Capacity ARL-CTY-E15-35

What It Does: Safely lifts and transports goods up to a height of 3.5 meters.
Key Strengths: High-quality steel construction with internal and external reinforcement for superior load capacity.
Safety First: Includes a dedicated foot protection design and a robust foot brake system.
Versatility: Features adjustable forks to accommodate various pallet sizes and loads.

Heavy-Duty Steel Construction

The forks are manufactured from high-quality steel plates. Both outer and inner reinforcements are integrated into the design to guarantee long-term durability and a strong load capacity even at maximum lift.

Precision Stability & Safety

Stability is critical when lifting to 3.5 meters. This model includes a foot brake to lock the stacker in place during loading. Additionally, the foot protection design ensures the operator remains safe from accidental injuries during movement.

Adjustable Loading Options

With adjustable forks ranging from 320mm to 750mm in width, this stacker is highly adaptable. It allows you to handle different pallet types and load configurations with ease.

Smooth Mobility

Equipped with high-quality Nylon or PU wheels, the stacker glides easily over warehouse floors. The large Φ180mm drive wheels and Φ80mm load wheels provide the perfect balance between maneuverability and weight distribution.

Technical Specifications

Specification	Details
Model	ARL-CTY-E15-35
Max. Load Capacity	1500 kg
Max. Lifting Height	3.5 m
Min. Fork Height	90 mm
Mast Height (Lowered)	2300 mm
Mast Height (Extended)	4030 mm
Forks Type	Adjustable
Fork Dimensions (LWH)	1150 x 150 x 60 mm
Forks Outside Width	320–750 mm
Net Weight	282/286 kg

Frequently Asked Questions (FAQ)

What is the benefit of the adjustable forks?

Adjustable forks allow you to move the width of the blades (from 320mm to 750mm) to fit different sizes of pallets or specialized equipment, making it much more versatile than a fixed-fork model.

How stable is the stacker when fully extended to 3.5m?

The stacker is designed with a reinforced steel mast and includes a foot brake system to lock the unit in position, providing the necessary stability for safe high-level lifting.

What type of wheels does it use?

It uses high-grade Nylon or PU (Polyurethane) wheels, which are designed to handle heavy loads while protecting your warehouse floor from marks and scratches.
