3-inch DC Solar Centrifugal Pump ARL-4SPW2-11-A

3-inch DC Solar Centrifugal Pump ARL-4SPW2-11-A

The 3-inch DC Solar Centrifugal Pump ARL-4SPW2-11-A is an efficient 3-inch DC solar centrifugal pump, designed for diverse water pumping applications. It is powered by an 1800W / 2.41HP BLDC motor and includes an external MPPT controller, enabling it to deliver a maximum head of 116 meters and a flow rate of 6.1 cubic meters per hour. The pump body is made from durable stainless steel, while the impeller material is also stainless steel. The encapsulated water-filled motor ensures no pollution risk and contributes to a longer operational life. With soft-start running and a robust thrust bearing system, this pump offers consistent performance and comprehensive protective features. It can be powered by both AC and DC sources, providing versatile power options.

Key Features:

• High Efficiency Motor: Equipped with an 1800W / 2.41HP BLDC high-efficiency, encapsulated water-filled motor.
• Durable Construction: Built with a stainless steel (AISI 304) pump body and impeller, ensuring longevity and corrosion resistance.
• External MPPT Controller: Features an external controller with MPPT function for optimized solar power utilization. The controller offers comprehensive protections including Dry-Run, Reverse, Phase Loss, Over-Voltage, Low-Voltage, Over-Current, Over-Load, Over-Power, Over-Temperature, Stall, and Error Display. The controller has an IP65 rating.
• Versatile Power Input: Supports both DC voltage (180-230V range) and AC voltage (150-240V range), offering flexibility in power sources.
• Informative Display: The controller displays voltage, current, power, and speed.
• Included Accessories: Comes with 1* 3inch DC solar centrifugal pump with 1* 1.5m cable, 1* Pump controller with MPPT function, 1* Electric float switch for water tank, 1* Waterproof adhesive tape, 1* PVC electrical adhesive tape, and 1* PTFE tape.
• System Advantages: Includes a non-return valve and soft start running for extended system life.
• Certifications: CE, TUV, SUD, UL, ISO9001, ISO14001 certified.
• Warranty: 2 Years.

Technical Specifications:

• Product Model: ARL-4SPW2-11-A
• Power: 1800W / 2.41HP
• Power Type: AC/DC
• Max Head: 116 meters
• Max Flow: 6.1 m³/h
• Outlet Size: 1.25 inches
• Impeller Material: Stainless Steel
• Impeller Type: Centrifugal
• Pump Body Material: Stainless Steel 304
• Motor Type: Water-Filled, PMSM / BLDC motor
• Motor Material: AISI 304
• Insulation Class: F
• Enclosure Class (Motor): IPX8
• Enclosure Class (Controller): IP65
• DC Voltage Range: 180-230V
• AC Voltage Range: 150-240V
• Optimal Voltage (Controller): 40-90Vmp/100Voc
• Max Voltage (Motor): DC Max. VOC 100V
• Optimal Voltage (Motor): DC Best. Vmp 40-90V
• Max DC Current: 15A
• Max Submersion: 150m
• Max Water Temperature: 40°C
• Motor Efficiency: Max. 85%
• Controller MPPT Efficiency: Max. 98%
• Required Cooling Flow (Motor): 0.5L/s
• Recommended Max Input (System): Max. 0.6kW
• Minimum Well Diameter: Min. 3 inches
• Pump Discharge: Rp 1.25
• System Efficient Max: 98%
• Bearing System: Thrust bearing system
• Gross Weight (Pump+Controller): 10.5 KG
• Net Weight (Pump+Controller): 8.5 KG
• Dimension (Pump+Controller): 61*36*16 MM

What’s Included:

• 1* 3inch DC solar centrifugal pump with 1* 1.5m cable.
• 1* Pump controller with MPPT function.
• 1* Electric float switch for water tank.
• 1* Waterproof adhesive tape.
• 1* PVC electrical adhesive tape.
• 1* PTFE tape.

Not Included (Self-Prepare):

• Suitable solar panels. (Recommend using 550W solar panels in series).
• A stainless steel wire (safety cable) to hold pump in bore.
• Poly pipe from pump to water tank.
• Pump outlet joint connector.
• Wire power cable (2 wires plus earth).

Notes:

• The Controller is IP 65 Rated; however, it is recommended that it is not mounted in direct sunlight.
• VOC (V) Volts open circuit nothing connected; Vmp (V) Volts maximum power point under load.
• Exceeding limits may cause serious harm or irreparable damage.
