4CH Video Quad Screen Real Time Recording System (ARL-MS-715RSW-4CH)

SKU: ARL-MS-715RSW-4CH Categories: 7 Inch Wireless system, Driving Control System, Full Screen Monitors, Monitors, Wireless Rear View System

Add to wishlist

4CH Video Quad Screen Real Time Recording System (ARL-MS-715RSW-4CH)

The 4CH Video Quad Screen Real Time Recording System (ARL-MS-715RSW-4CH) is a robust, interference-free digital wireless recording system ideal for industrial applications. Operating in the 2400MHz~2483.5MHz range with auto scanning and pairing, it supports 4 video channels displayed on a quad screen. It offers real-time recording to a MAX 128GB SD card, providing up to 142 hours (single channel) or 36 hours (four channels), with selectable recording options. 4CH Video Quad Screen Real Time Recording System – Wireless, HD Display Integrated video playback allows for easy review. Built to withstand harsh environments, it resists shock (100G) and vibration (20G), features a dustproof and waterproof design with sealed connectors, and operates reliably in extreme temperatures. 4CH Video Quad Screen Real Time Recording System – Wireless, HD Display wireless range extends up to 1500 meters in open areas.

This system features a high-definition 7-inch digital panel with a 1024 x 600 resolution and a 16:9 aspect ratio, delivering clear visuals with a 350cd/m2 brightness and a 1000:1 contrast ratio. It offers wide viewing angles and operates on a flexible DC 10-36V power supply with low power consumption. Designed for industrial use, it meets stringent requirements for durability and performance.

Key Features:

Interference-Free Digital Wireless
4CH Video & Quad Screen Display
Real-Time SD Card Recording (Max 128GB)
Selectable Recording Channels (1-4)
Integrated Video Playback
Long Wireless Range (Up to 1500M Open Area)
Industrial-Grade Shock and Vibration Resistance
Dustproof and Waterproof Design
Wide DC Voltage Input (10-36V)
High-Definition 7-inch Display (1024×600)
Wide Viewing Angles

Technical Specifications:

Feature	Specification
Model	ARL-MS-715RSW-4CH
Signal Type	No interference digital signal
Frequency	2400MHz ~ 2483.5MHz
Pairing	Auto scanning, auto pairing
Video Channels	4
Display	Quad screen
Recording	Real time, MAX 128GB SD card
Recording Time (1 CH)	~142 hours
Recording Time (4 CH)	~36 hours
Recording Options	1/2/3/4 channel optional
Video Playback	Yes
Shock Resistance	100G force
Vibration Resistance	20G force
Dust and Waterproof	Yes, all connectors are waterproof
Operating Environment	Hot and cold weather, shock, vibration resistant
Panel Size	7” digital panel
Screen Ratio	16:09
Resolution	1024 * 3R.G.B * 600
Back Light, Luminance	LED, 350cd/m2
Contrast	1000:01:00
Viewing Angle (U/D/L/R)	UP–50º, DOWN–70º, LEFT–70º, RIGHT–70º
Transmitting Distance	1500M (open area)
Power Supply	DC 10-36V
Power Consumption	<5W
Maximum Current	<550mA
Working Temperature	-20 to 60 ºC
Storage Temperature	-20 to 70 ºC
