5.6” Color LCD Monitor – Multi-Input, Adjustable View (ARL-MS-566)

The ARL-MS-566 is a versatile 5.6-inch digital reversing camera system designed to enhance vehicle safety. 5.6” Digital Reversing Camera System supports up to three video input channels and one audio channel, with an option for two video inputs. 5.6” Color LCD Monitor – Multi-Input, Adjustable View (ARL-MS-566) offers a wide viewing angle and high-resolution display, ensuring clear and comprehensive visuals. Its picture image can be adjusted for horizontal, vertical, mirror, and normal viewing modes, providing flexibility for various setups. Catering to diverse installation needs, it features an intuitive user interface with eight selectable languages and comes equipped with a full-function remote controller for convenient operation. The system automatically detects PAL and NTSC video formats. It intelligently switches to back-up, left, or right side camera views when triggered, and includes a three-way reversing function with adjustable camera image and integrated audio cues.

The 5.6-inch screen features a 4:3 aspect ratio and a resolution of 320 x RGB x 234, delivering a clear picture with a contrast ratio of 300:1 and a brightness of 330cd/m2. The visible viewing angles are 40 degrees upwards, 60 degrees downwards, and 60 degrees to both the left and right. The on-screen display (OSD) menu supports eight languages. The monitor automatically adapts to PAL/NTSC video systems and functions within a wide operating power range of DC10~36V. It is designed to withstand operating temperatures from – 20℃ to +70℃ and storage temperatures from – 30℃ to + 80℃.

Key Features:

  • 5.6” Digital Reversing Camera System
  • Supports up to 3 Video Inputs & 1 Audio Input
  • Wide Viewing Angle & High Resolution
  • Adjustable Image (Horizontal/Vertical/Mirror/Normal)
  • Versatile Installation Options
  • 8 Selectable OSD Languages
  • Full-Function Remote Controller
  • Auto PAL/NTSC Support
  • Wide Voltage Input (DC 10V ~ DC 32V)
  • Automatic Switching for Backup/Side Views
  • Three-Way Reversing Function with Adjustable Image & Audio

Technical Specifications:

Feature Specification
Model ARL-MS-566
Screen Size 5.6”
Picture Display Format 4:3
Resolution 320 * RGB * 234
Contrast 300:1
Brightness 330cd/m2
Visible Angle (U/D/L/R) U:40 / D:60, L/R : 60
Language Display 8 languages OSD menu
Video System Automatic PAL/NTSC
Operating Power DC10 ~ 36V
Operation Temperature – 20℃ ~ +70℃
Storage Temperature – 30℃ ~ +80℃
Video Input Up to 3 channels (2 channels optional)
Audio Input 1 channel
Image Adjustment Horizontal, Vertical, Mirror, Normal
Remote Controller Full-function
Automatic Switching Backup, Left, Right Side Views
Reversing Function Three-way with adjustable image
