9.66-inch Streaming Media Rearview Mirror System with WDR ARL-MS-649

 9.66-inch Streaming Media Rearview Mirror System with WDR (ARL-MS-649)

The ARL-MS-649 is an advanced streaming media rearview mirror system featuring a high-definition 9.66-inch IPS touchscreen display with a resolution of 1280x320P. It integrates front and rear cameras, both recording in crisp 1080P (1920X1080) resolution. The front camera offers flexible adjustment with left/right and up/down positioning. With a wide viewing angle of 170° for the front camera and 140° for the rear, it captures a comprehensive view of your surroundings. The AHD rear camera is equipped with Wide Dynamic Range (WDR) technology, ensuring clearer images in low-light conditions and reducing glare from headlights. Its 24-hour parking monitoring feature utilizes time-lapse recording after the vehicle is turned off, capturing one frame per second with video saved before and after the event. The system is powered by an MSTAR (MSC8336) ARM Cortex A7 800 MHz processor with 512MB DDR3 RAM and 32MB Flash memory.

Key Features:

• 9.66-inch IPS Touchscreen: Large, high-resolution display for clear viewing and easy operation.
• Dual 1080P Cameras: Front and rear cameras record in Full HD (1920×1080).
• Adjustable Front Camera: Offers left/right and up/down manual adjustment for optimal positioning.
• Wide Viewing Angles: 170° front camera and 140° rear camera capture a broad field of view.
• AHD Rear Camera with WDR: Enhances image clarity in low light and reduces headlight glare.
• Optional Day/Night Mode: Optimizes display for different lighting conditions.
• 24-Hour Parking Monitoring: Utilizes time-lapse recording for continuous surveillance while parked (optional 5V adapter may be required).
• Built-in G-Sensor: Automatically locks video files upon detecting collisions.
• Loop Recording: Ensures continuous recording by overwriting the oldest unlocked files.
• Automatic Start: Begins recording automatically when the vehicle is powered on.
• Multi-Language Support: Supports English, Chinese, and Japanese.
• Large Storage Capacity: Compatible with Micro SD cards up to 64GB (not included).

Technical Specifications:

• CPU: MSTAR (MSC8336) ARM Cortex A7 800 MHz
• DDR: DDR3 512MB
• FLASH: 32MB BIT
• Screen: 9.66 inch IPS Full Touch, 1280*320
• Front Lens Sensor: Smartsens SC2063 1/2.9” CMOS
• Front Lens Angle View: 170°
• Front Cam Video Resolution: 1920*1080, 30FPS
• Back Cam: TVI 1080P
• Back Cam Resolution: 1920*1080, 30FPS
• Back Cam Lens Angle View: 140°
• Video Format: MOV
• Image Format: JPG
• Touch: TPS Support
• G-Sensor: Support (Three-axis collision acceleration sensor)
• Auto Reverse: Support
• Parking Monitor: Support (Optional, requires 5V adapter)
• Storage Temperature: -20°C to 70°C
• Operating Temperature: 0°C to 65°C
• Video Mode: Loop recording
• Language: English, Chinese, Japanese
• TF Card: Maximum support 64GB Micro SD card (not included)
• Battery: Without battery
• Auto Start: Support (video recording when power on)
• Video Code: H.264

This streaming media rearview mirror system offers a comprehensive solution for capturing your drives with high-definition front and rear recording, enhanced low-light performance, and convenient features for both driving and parking scenarios.
