Duct Ventilation Fan ARL-BPT20-30/35-31(P6A) Series

Duct Ventilation Fan

Introducing the Duct Ventilation Fan, crafted with an all-plastic body for durable and reliable performance in ducted systems. These fans are designed to efficiently move large volumes of air, ensuring effective ventilation for maintaining optimal indoor air quality. With models offering slightly varied performance metrics, this series provides flexible solutions for diverse ventilation needs, all while maintaining a consistent and robust construction.

Key Features:

• All-plastic body construction for durability
• Designed for efficient ducted ventilation
• Capable of moving large air volumes
• Suitable for applicable areas of 25-30 m²
• Compact and integrated design for easy installation

Technical Specifications:

Model: ARL-BPT20-30-31(P6A)

• Power: 45 W
• Air Volume: 300 m³/h
• Pressure: 138 Pa
• Speed: 630 r/min
• Noise Level: 42 dB(A)
• Opening Size: 235×235 mm
• Applicable Area: 25-30 m²
• Quantity (per package): 4 Pc
• Gross Weight: 11 Kg
• Packaging Dimensions (L x W x H): 845x390x400 mm
• 3C Certification: Yes
• Energy Efficiency Rating: 2
• Overall Dimensions (A x B x C x D x E x F): 365 x 17 x 357 x 309 x 185 x 41 mm
• Pipe Diameter (G): Ø140 mm

Model: ARL-BPT20-35-31(P6A)

• Power: 45 W
• Air Volume: 354 m³/h
• Pressure: 148 Pa
• Speed: 730 r/min
• Noise Level: 46 dB(A)
• Opening Size: 235×235 mm
• Applicable Area: 25-30 m²
• Quantity (per package): 4 Pc
• Gross Weight: 11 Kg
• Packaging Dimensions (L x W x H): 845x390x400 mm
• 3C Certification: Yes
• Energy Efficiency Rating: 2
• Overall Dimensions (A x B x C x D x E x F): 365 x 17 x 357 x 309 x 185 x 41 mm
• Pipe Diameter (G): Ø140 mm
