7″ 4CH 1080P HD Mobile Video Recording System with GPS ARL-MS-715DVR

7″ 4CH 1080P HD Mobile Video Recording System with GPS (ARL-MS-715DVR)

The ARL-MS-715DVR is a robust 4-channel high-definition mobile video recording system designed for a wide range of vehicle applications. 7″ 4CH 1080P HD Mobile Video Recording System with GPS (ARL-MS-715DVR) supports up to 4 camera inputs with various analog formats including CVBS, 960H, and AHD, with resolutions up to 1080P. The system utilizes efficient H.264 video compression and features a clear 7-inch monitor with a resolution of 1024 x 600 pixels for live viewing and playback. It operates on a stable Linux operating system and offers an optional touchscreen interface for easy control. Storage options include SD memory cards up to 256GB and optional SSD support for expanded capacity. A built-in GPS module enables accurate location tracking. The system is designed with a professional in-vehicle power supply supporting a wide 9-36V DC input range and includes built-in circuit protection against overvoltage and reversing voltage.

Key Features:

• 4CH HD Recording: Supports up to 4 high-definition video channels with 4-split screen display.
• Versatile Camera Compatibility: Compatible with CVBS, 960H, and AHD cameras.
• High Video Quality: Records video at resolutions up to 1080P.
• 7-inch High-Resolution Monitor: Clear display with 1024 x 600 pixel resolution.
• Optional Touchscreen: Provides intuitive user interface control.
• Flexible Storage: Supports SD memory cards up to 256GB and optional SSD.
• Built-in GPS: Enables accurate location tracking and map display.
• External USB Interface: Allows for product upgrades and file downloads.
• Multiple Recording Modes: Supports manual, alarm-triggered, timed, and triggered recording.
• Additional Trigger Inputs: Features 4 additional trigger inputs for event-based recording.
• Multiple Display Modes: Offers Full CH, Auto Scan, Trigger CH, and Live display options.
• Audio Input Control: Supports turning audio input on or off.
• Comprehensive File Information: Records date & time stamp, vehicle information, GPS data, and channel number on the video file.
• On-Device Playback: Allows for direct playback of recorded files on the LCD monitor.
• Intuitive Setup Menu: Easy configuration via the LCD menu.
• Map Tracking Available: Displays vehicle location on a map.
• G-sensor Applicable: Supports G-sensor for impact detection.
• Robust Power Protection: Built-in circuit protection against overvoltage and reversing voltage.
• Wide Voltage Input: Professional in-vehicle power design supports 9-36V DC.

Technical Specifications:

• Channels: 4 Video Inputs
• Video Compression: H.264
• Operating System: Linux
• Monitor Size: 7 inch
• Monitor Resolution: 1,024 x 3(RGB) x 600 Pixels
• Video Resolution: Up to 1080P
• Storage: SD Card (Max. 256GB), Optional SSD
• GPS: Built-in
• USB Interface: External USB2.0
• Power Input: 9-36V DC
• Camera Support: CVBS/960H/AHD
• Audio Input: On/Off Control

This 7-inch 4CH 1080P HD Mobile Video Recording System offers a comprehensive and reliable solution for vehicle surveillance with high-quality recording, GPS tracking, and versatile storage options.
