LED Explosion Proof Flood Light – High Lumen, Curved Fin Design

LED Explosion Proof Flood Light – High Lumen, Curved Fin Design | Model: ARL-J Series

At a Glance: LED Explosion Proof Flood Light | Model: ARL-J Series

• Primary Use: Area and flood lighting in hazardous locations.
• Key Benefit: Long lifespan ($\ge 50,000\text{ hrs}$), high luminous efficiency ($\ge 140\text{lm/W}$), and curved fin design for maximum heat dissipation.
• Built For: Explosive gas and dust environments (Zone 1, Zone 2, Zone 21, Zone 22), including marine applications due to UL1598A anti-corrosion rating.

Your Solution for Safe, Powerful, and Reliable Area Illumination

The LED Explosion Proof Flood Light (ARL-J Series) is a high-performance fixture engineered for demanding industrial and hazardous locations. Designed to significantly reduce maintenance costs, the fixture boasts a lifespan of over $50,000\text{ hours}$. Its unique Curved Fin Shape maximizes heat transfer, ensuring optimal performance and longevity. With a well-designed optical system and high luminous efficiency, it provides powerful, reliable illumination while meeting strict international safety standards for explosive environments.

Features that Drive Performance

• Thermal Management: Features a Private mold designed Curved Fin Shape housing made of ADC12 die-cast aluminum to maximize heat dissipation.
• Safety and Protection: Certified for Zone 1&21 and Zone 2&22 hazardous areas. The enclosure is designed with a tempered glass lens for superior shock and vibration resistance.
• High Efficiency: Provides high luminous efficiency of $\ge 140\text{lm/W}$ and a high power factor of $\text{PF}>0.95$.
• Durability: Rated for $\ge 50,000\text{ hours}$ lifespan (L70) and protected with a high protection grade of IP66.
• Marine Ready: The UL1598A North American marine anti-corrosion rating ensures safe use in marine environments.
• Flexible Light Control: Offers beam angle options of 90∘ and 120∘ to meet diverse lighting requirements.
• Robust Circuitry: Features $4\text{KV}/6\text{KV}$ Surge Protection power supply.

Technical Specifications Table

Note: All models are available in $100-277\text{Vac}$ and $277-480\text{Vac}$ voltage options.

Frequently Asked Questions (FAQ)

What types of hazardous environments is the LED Flood Light suitable for? It is suitable for Zone 1&21 and Zone 2&22 explosive environments. It is widely used in oil refining, chemical industry, electric power, metallurgy, and military industries. Due to its UL1598A anti-corrosion rating, it is also highly suitable for marine applications.

Is an emergency function available for this flood light? Yes, an optional emergency power supply is available. The system features a $12\text{W}$ emergency power output, providing an emergency time of $290\text{ minutes}$ from an $11.1\text{V}/2500\text{mAH}$ Li-ion battery.
