Automotive Grade Mirror Camera System (ARL-MS-719 A)

The Automotive Grade Mirror Camera System ARL-MS-719 A is a highly reliable, automotive-grade mirror camera system built with AEC Q100 certified main control and COMS chips, ensuring exceptional durability and performance. Automotive Grade Mirror Camera System (ARL-MS-719 A) features a choice of a wide viewing angle HD LCD in 10.25, 12.3, or 14.5-inch sizes and supports up to 256GB of memory. This versatile system handles two-way CVBS or mixed AHD video inputs with hot-swapping capability, allowing simultaneous dual-channel recording and local playback. It supports native 1080P digital signal input and offers flexible display options with automatic brightness adjustment. Designed for automotive environments, it provides a 12V power output for cameras, boasts a fast boot-up, and includes an optional infrared remote control.

Key Features:

Automotive Grade Reliability: Built with AEC Q100 certified main control and COMS chips for dependable performance.
Large HD Display Options: Choice of 10.25, 12.3, or 14.5-inch full viewing angle HD LCD.
High Memory Capacity: Supports up to 256GB for extensive recording.
Flexible Video Input: Compatible with two-way CVBS or mixed AHD, with hot-swapping functionality.
Simultaneous Dual-Channel Recording: Records from two channels concurrently in separate folders.
Local Video Playback: Allows direct review of recorded footage on the device.
Native 1080P Input: Supports dual channels of 1080P digital signals at 30/60fps.
Versatile Display Output: Supports single/double LVDS/RGB formats at 1920*1080 with horizontal and vertical rotation options.
Adaptive Brightness: Automatic adjustment of screen brightness via a light sensor.
Integrated Camera Power: Provides a stable 12V power output for connected cameras.
Fast Boot-up: System starts up quickly in approximately 4 seconds.
Optional Remote Control: Infrared remote control available for added convenience.
Efficient Synchronization: COMS and display synchronization speed of 12-20ms.
Vertical Screen Compatibility: Supports signal access and conversion for vertical screen displays.

Technical Specifications:

Feature	Specification
Video Input/Display Resolution	1920*1080 (Backward Compatible)
Display Ratio & Mode	Horizontal or Vertical (5:5/6:4/7:3/8:2)
Video Input Format/Frame Rate	SDI Digital Signal 30fps
Image Display	Horizontal / Original Image
Brightness / Color / Contrast	Customizable
Loop Recording	1 / 3 / 5 Minutes (Customizable)
Reverse Delay	3-10 Seconds (Customizable)
Menu Language	Simplified Chinese, English (Customizable)
LCD Interface	RGB16bit / Single & Double LVDS / Sa-Si TFT / MIPI-LCD
Number of Channels	Two Channels Displayed Simultaneously
Video Source Input	1.0Vp-0.2vpp
Audio Port	PCM
Storage Support	Maximum 256G Capacity
Reverse Trigger	7.5V-36V
Infrared Remote Control	Built-in Receiver
Power Output (Camera)	DC Two-Channel 12V/3A
Light Brightness Sensor	Automatic Screen Brightness Adjustment
Button Interface	Multi-Key Control (0.1-3.3V)
Backlight Interface	Maximum Voltage 45V, 300mA
Power Input	DC12-36V
Video Resolution (Recording)	Dual Channel Independent Recording 1920*1080p
Compression Format	H.264
File Format	TS (No Lost Seconds on Power Off), AVI
Power Consumption	3.7W
Working Temperature	-40 degrees to +85 degrees Celsius
Storage Temperature	-40 degrees to +125 degrees Celsius, Relative Humidity less than 90%
AHD Video Signal Output	Customizable
COMS Display Sync Error	15-25MS
Version Size	110mm * 77mm * 15mm
