Fixed Multi Gas Monitor ARL-MIC600 Series

Fixed Multi Gas Monitor ARL-MIC600 Series

The ARL-MIC600 Fixed Multi Gas Monitor ARL-MIC600 is a high-performance stationary gas detection system designed for continuous environmental monitoring. It features a standard data storage capacity of 100,000 entries with optional SD card expansion, supporting real-time, fixed-time, or alarm-only data logging. The ARL-MIC600 is equipped with a 2.5-inch high-definition color screen that displays real-time concentrations, curves, and environmental data using high-definition simulation graphics. Designed for versatility, it can be customized for extreme conditions, including smoke gas detection up to 1300 °C when utilizing an optional high-temperature pretreatment system.

Key Features:

• Advanced Data Management: Standard storage for 100,000 entries with the ability to view, delete, or upload data via an RS485 interface to a computer.
• High-Definition Display: Uses a 2.5-inch color screen to simultaneously show multiple gas concentrations, real-time curves, and a graphical menu interface.
• Extreme Temperature Capability: Detects gases at standard temperatures or up to 1300 °C with optional high-temperature and high-humidity pretreatment systems.
• Durable Design: Rated with IP66 and Exd II CT6 approvals for operation in demanding industrial environments.
• Versatile Mounting: Supports both Wall Mounting and Pipeline Type installation to suit various facility requirements.
• Comprehensive Monitoring: Tracks THT, temperature, humidity, and pressure with customizable detection ranges.

Technical Specifications:

• Test Items: THT, Temperature, Humidity, and Pressure.
• Detection Range: 0–100 ppm (standard), with other ranges available for customization.
• Data Storage: 100,000 entries standard; optional SD card storage function.
• Working Environment: Temperature range of -40 °C to +70 °C; humidity ≤ 10 to ≤ 95% RH.
• Physical Dimensions: 210 * 170 * 85 mm (L*H *W).
• Weight: 1.8 kg.
• Power & Installation: Supports 24VDC or 220AC sampling pumps; installation via wall brackets, pipe clips, or flanges.
• Optional Accessories: Wireless transmission, alarms, rain cover, and vacuum pumps with sampling distances up to 40 m.
