LVDS Camera
This high-performance LVDS (Low-Voltage Differential Signaling) camera is designed for demanding applications, particularly in automotive and industrial settings. It features a 1080P camera system built around an OV 2MP OX03C10 sensor and an FH8322 ISP, capturing high-resolution video at 920*1080@30fps. Engineered for durability, it boasts an IP67 waterproof rating and can withstand significant impact with a rating of 20G vibration and 100G shock. The camera offers a horizontal field of view (HFOV) of 90±3° and a vertical field of view (VFOV) of 50±3°. It excels in challenging lighting conditions with a High Dynamic Range (HDR) of ≥120dB. The power source requirement is DC 6-16V, and the video output format is uyvy422_8bit, utilizing a MAX9295 serializer. The image output can be configured for normal or mirror view. This camera is designed for a wide operating temperature range of -40 to +85℃.
Key Features:LVDS Camera
- High Definition: 1080P camera system (2MP sensor).
- High Frame Rate: Captures video at 920*1080@30fps.
- Wide Dynamic Range: HDR ≥120dB for excellent image quality.
- Wide Viewing Angle: HFOV 90° and VFOV 50°.
- Robust Design: IP67 waterproof and high impact rating (20G/100G).
- Wide Power Input: Compatible with DC 6-16V.
- Flexible Image Output: Supports normal and mirror image.
- Wide Operating Temperature: Suitable for extreme conditions (-40 to +85℃).
- LVDS Output: Utilizes MAX9295 serializer.
Technical Specifications: LVDS Camera
Applications: LVDS Camera
- High-Definition 2MP+/4MP 60fps Camera Systems
- Surround View
- ADAS (Advanced Driver-Assistance Systems)
- CMS (Camera Monitoring Systems)
- RVC (Rear View Camera)
- Gesture Recognition
- 8MP 40fps Front-View Cameras
- Satellite LiDAR and RADAR sensors
