Damping electric butterfly valve

Damping electric butterfly valve

The Damping Electric Butterfly Valve is a specialized valve designed for controlling the flow of high-temperature flue gas. This robust valve features a versatile range of body and disc materials, including Cast Iron, Ductile Iron, and various grades of Stainless Steel such as CF8M and CF3M. Built for industrial efficiency, the Damping Electric Butterfly Valve supports a wide range of flange accommodations and offers both ON-OFF and adjustable actuator types to suit diverse operational needs.

Key Features:

• Actuator Flexibility: Equipped with an electric actuator available in ON-OFF or adjustable types.
• Broad Compatibility: Suitable for handling mediums such as Gas, Water, and Oil.
• Versatile Sizing: Available in sizes ranging from 2″ to 120″ (25mm – 3000mm).
• Safety Options: Offers optional explosion-proof actuators (Exd II CT5, Exd II BT5) for hazardous environments.
• Precise Control: Features control signal options of 4-20 mADC, 0-5 VDC, or 0-10 VDC.

Technical Specifications:

• Materials: Body and Disc available in Cast Iron, Ductile Iron, and Stainless Steel (CF8, CF8M, CF3M).
• Seats & Stem: Constructed from durable Stainless Steel.
• Pressure Rating: Rated for 0.6Mpa.
• Flange Accommodations: Supports EN 1092 PN 6/PN10/PN16, ASME Class 150, AS 4087 PN 10/PN 16, and JIS 5K/10K.
• Power Supply: Compatible with 12 VDC, 24 VAC/VDC, 220 VAC, 120 VAC, and 380 VAC (50/60 Hz ±10%).
